High-Efficiency Ammonia Nitrogen Stripping System for Sewage Treatment
Ammonia nitrogen stripping technology offers a mature and highly efficient solution for treating ammonia-rich wastewater. By leveraging pH adjustment and temperature control, this process effectively converts dissolved ammonia (NH₄⁺) into gaseous ammonia (NH₃) for removal. Key operational parameters include:
pH Adjustment: Wastewater pH is elevated to ≈11.5 (via变频-controlled dosing) to favor NH₃ formation.
Temperature Control: Maintained above 50°C to enhance stripping efficiency.
Two-Stage Countercurrent Design: Ensures thorough ammonia removal while minimizing chemical usage.
Raw water mixed with coagulant enters a coagulation tank equipped with an mechanical mixer. This ensures uniform reaction between coagulants and suspended solids, forming stable "rock flowers" (flocs). Unlike traditional vortex reactors, the mixer-driven design guarantees consistent performance regardless of flow fluctuations.
Floc-loaded water flows into an inclined tube sedimentation tank. The梯形斜板沉淀室 (trapezoidal inclined plate sedimentation chamber) accelerates solid-liquid separation, directing sludge to a collection hopper while clarified water proceeds to filtration.
First-Stage Stripping: pH-preadjusted wastewater (pH≈11.5) is pumped into the primary stripping tower. Post-stripping, pH drops, necessitating supplementary caustic soda dosing.
Second-Stage Stripping: Wastewater undergoes further pH elevation (back to ≈11.5) before entering the secondary tower for final ammonia removal.
Countercurrent Flow: Maximizes gas-liquid contact for optimal NH₃ extraction.
Treated water passes through multi-media filters (e.g., sand/activated carbon) for residual solids removal, followed by water stabilization (e.g., pH correction) to prevent corrosion/scaling in downstream systems.
Filters are automatically backwashed via programmed controllers or siphon-driven mechanisms when head loss exceeds thresholds, ensuring uninterrupted operation.
Parameters
| Type | AF-1 | AF-7.5 | AF-10 | AF-15 | AF-20 | AF-40 | |
| Capacity m³/h | 1 | 7.5 | 10 | 15 | 20 | 40 | |
| Equipment No. | 1 | 1 | 2 | 2 | 2 | 4 | |
| Sludge Absorb | 1.8 | 14 | 18 | 27 | 36 | 82 | |
| Contact oxidation tank(m3) | S.0 | 36 | 44 | 63 | 83 | 170 | |
| secondary sedimentation tank surface load (m³/m²h) | 1.2 | 1.3 | 1.2 | 1.2 | 1.5 | 1.5 | |
| disinfecting tank(m³) | 0.6 | 4 | 5.5 | 8 | 10 | 20 | |
| Blower | HC-25IS | HC-50IS | HC-60IS | HC-80S | HC-100S | HC-100S | |
| Power(kw) | 0.4 | 2.2 | 2.2 | 3.7 | 5.5 | 5.5x2 | |
| No. | 2 | 2 | 2 | 2 | 2 | 3 | |
| Pump type | AS10-2CB | AS16-2CB | AS30-2CB | ||||
| Power(kw) | 1 | 1.6 | 2.9 | ||||
| Heaviest Set(t) | 5 | 10 | 8 | 10 | 10.5 | 10.5 | |
| Total Weight(t) | 5.5 | 11 | 17 | 20 | 21 | 38 | |
| floor space(m²) | 6 | 30 | 50 | 65 | 75 | 155 | |
