| 起源の場所: | 中国 |
| ブランド名: | Dongdai |
| 証明: | 9001 |
| モデル番号: | ZTFS |
| 最小注文数量: | 1セット |
|---|---|
| 価格: | Negotiatable |
| パッケージの詳細: | 輸出polywood |
| 受渡し時間: | 3〜5週間 |
| 支払条件: | T/T,WeChat Pay,Alipay メールで受け取る |
| 供給の能力: | 年間1000セット |
| 材料: | ステンレス鋼、合金金属 | 応用: | 廃水 |
|---|---|---|---|
| 保証: | 2年 | 製品名: | ゴミの焼却炉 |
| 提供されるアフターセールスサービス: | 海外で機械にサービスを提供できるエンジニア | 色: | 顧客の要求に応じて |
| 寸法（l*w*h）: | モデルによると | 名前: | Tianniweiネジ型スラッジ脱水機 |
| 電圧: | 顧客の要件 | 自動グレード: | 自動 |
| 状態: | 新しい |
Chin
Microwave Sterilization & Waste Incineration Integrated Treatment System
Our core microwave thermal sterilization technology utilizes both thermal and non-thermal effects to eliminate pathogens efficiently. Microwaves (frequency: 300 MHz–300 GHz) penetrate biological cells—complex condensed media composed of water, proteins, nucleic acids, carbohydrates, and fats—causing rapid temperature rise and structural breakdown. This process denatures proteins, disrupts cellular activity, and ensures complete sterilization without chemical residues.
Key Mechanisms:
Thermal Effect: Rapid heating destroys cell integrity.
Non-Thermal Effect: Electromagnetic field disruption deactivates pathogens at molecular levels.
| Model | Dimensions (L×W×H mm) | Capacity (kg/batch) | Chamber Volume (m³) | Power (kW/h) | Fuel Consumption (L/h) | Weight (t) |
|---|---|---|---|---|---|---|
| ZTFS-20-40 | 1200×1300×1800 | 20–40 | 3.0 | 2–4 | 3–8 | 2.2–5.5 |
| ZTFS-20-60 | 1700×1500×2100 | 20–60 | 5.0 | 2–5 | 3–10 | 4.5–7.8 |
| ZTFS-50-120 | 2200×2000×2500 | 50–120 | 10.0 | 3–12 | 4–15 | 5.0–11.5 |
| ZTFS-100-300 | 3000×3500×2900 | 100–300 | 13.0 | 10–30 | 10–40 | 15–25 |
| ZTFS-400-500 | 3000×3700×3200 | 400–500 | 17.0 | 40–50 | 50–60 | 30–45 |
Our integrated systems are designed for harmless treatment of:
Medical waste (infectious materials, sharps, pharmaceuticals)
Domestic refuse
Animal carcasses
Primary Combustion: Waste is ignited at 800–950°C in the primary chamber.
Secondary Combustion: Gases are reburned at 1,100–1,200°C to eliminate toxins.
Gas Treatment: Cyclone dust collectors remove particulates; cleaned emissions are discharged via chimney.
Automation: Integrated pre-treatment, incineration, and dust removal systems reduce manual intervention.
Waste moves through inclined grates divided into zones:
Drying Zone: Moisture evaporation.
Combustion Zone: Primary burning.
Burn-Out Zone: Complete ash formation.
Combustion air mixes with waste from below, ensuring efficient burnout. Flue gases cool via boiler heat exchange, generating steam while reducing temperature before emission treatment.
Microwave Sterilization Unit: For non-thermal pathogen destruction.
Incineration Modules: Primary/secondary chambers, grate systems.
Gas Treatment: Cyclone dust collectors, chimneys, flue pipelines.
Auxiliary Systems: High-pressure blowers, induced draft fans, control cabinets.
Monitoring: Temperature sensors, automated detection devices.
We prioritize functional reliability over aesthetic appeal. Our expertise covers:
Wastewater treatment equipment (bar screens, air flotation devices, dosing systems, sludge scrapers).
Solid waste incineration and microwave sterilization solutions.
Customized designs based on your parameters, flowcharts, and operational demands.
Contact us within 12 hours for tailored technical proposals.
Dual-Technology Integration: Microwave sterilization + incineration for maximum safety.
Energy-Efficient: Low fuel consumption and power usage across models.
Environmentally Compliant: Meets international emission standards (EPA, EU).
Scalable Capacity: From 20 kg to 500 kg/batch options.
Turnkey Solutions: From design to installation and maintenance support.
Packing and Delivery
1. Waterproof packing with the international export standard by 20ft, 40ft, 40hp container. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
2. The whole plant machinery size are large as normal, so we will use Waterproof cloth to pack all of them. The motor, gear box or other easily damaged parts, we will put them into box. We have a professional shipping department, they will try their best to save your container quantity.
FAQ:
Q: Are You Trading Company Or Manufacture?
A: We Are Both Manufacture And Trading Company. We Have Over 30 Years' Professional Experience As a Waste Water Treatment Equipment Manufacturer And Engineering Service Enterprise.
Q : What Are Your Main Products?
A:Keywords :Sludge Dewatering Machine Equipment, Screw Type Sludge Dewatering Press Sludge Screw Press, Dewatering Sludge Machine Screw Press ,Sewage Treatment Equipment ,Sludge Treatment Plant,Screw Press Sludge Dewatering ,Dewatering Sludge,Dewatering Machine For Sludge, Dewatering Sludge Machine Screw Press, Rotary Drum Bar Screens, Equipment DAF, DAF Price ,Dissolved Air Flotation System Price, Sludge Shaftless Screw Conveyor,Chemical Dosing Device ,MBBR Price,MBBR Media,Disc Diffuser, Polymer Preparation Chemical Dosing System, and other customized machines.
Q: How Can I Find The Suitable Model?
A: Please Provide Flow Rate, Solids Content And Sludge Type, or directly contact us by the clicking the “contact” icon. We Can Assist You In Model Selection.
