China-Made Living Incinerator: Durable & Easy-Operation Machine for Garbage and Medical Waste
Our China-manufactured living incinerator machine offers a robust and user-friendly solution for the safe disposal of both general garbage and medical waste. Engineered for durability and simple operation, this system ensures efficient, high-temperature destruction of waste materials, making it an ideal choice for various applications requiring reliable and harmless waste treatment.
Easy Operation: Designed with user-friendly controls for straightforward and hassle-free operation.
Durable Construction: Built with high-quality materials to ensure long-lasting performance even under demanding conditions.
Versatile Application: Suitable for burning general garbage, medical waste, and other sanitary disposal needs.
Efficient Combustion: Achieves high-temperature incineration with minimal residue and emissions.
Compact & Scalable: Available in multiple sizes to meet different capacity requirements.
This incinerator is widely used for harmless treatment of:
Medical waste (plastic, glass, residual medicines)
Domestic garbage
Animal carcasses
Other combustible waste materials
By utilizing high-temperature combustion fueled by coal, oil, or gas, the incinerator effectively sterilizes and reduces waste to harmless ash, ensuring compliance with environmental and health standards.
| Model | Dimensions (mm) | Capacity (kg/batch) | Volume (m³) | Power Consumption (kW/h) | Fuel Consumption (L/h) | Weight (t) |
|---|---|---|---|---|---|---|
| ZTFS-25 | 1000×900×1700 | 25 | 2.5 | 2 | 3 | 1.15 |
| ZTFS-20-40 | 1200×1300×1800 | 20–40 | 3.0 | 2–4 | 3–8 | 2.2–5.5 |
| ZTFS-20-60 | 1700×1500×2100 | 20–60 | 5.0 | 2–5 | 3–10 | 4.5–7.8 |
| ZTFS-50-120 | 2200×2000×2500 | 50–120 | 10.0 | 3–12 | 4–15 | 5.0–11.5 |
| ZTFS-100-300 | 3000×3500×2900 | 100–300 | 13.0 | 10–30 | 10–40 | 15–25 |
| ZTFS-400-500 | 3000×3700×3200 | 400–500 | 17.0 | 40–50 | 50–60 | 30–45 |
Loading: Waste is manually loaded into the primary combustion chamber.
Primary Combustion: The automatic temperature control system initiates the first combustion phase, ensuring full oxidation and pyrolysis based on the Three T principle (Temperature, Time, Turbulence).
Secondary Combustion: Resulting gases move to the secondary chamber, where a dedicated burner and air supply system ensure complete destruction of any remaining harmful substances.
Emission Control: The treated gases pass through a dust collector to remove particles before being safely discharged via the chimney.
Ash Removal: Post-combustion ash is manually removed for further screening and disposal.
This process guarantees a destruction efficiency of over 99%, ensuring odor-free, smokeless operation that meets national emission standards.
Primary and secondary combustion chambers
Cyclone dust collector
Chimney and flue system
Piping network
High-pressure blower and induced draft fan
Primary and secondary burners
Electrical control cabinet
Temperature indicators and detection devices
High Efficiency: Achieves complete waste breakdown with minimal environmental impact.
Reliable Performance: Durable design ensures consistent operation with low maintenance.
Ease of Use: Simple manual loading and automatic combustion control reduce operational complexity.
Eco-Friendly: Meets stringent emission standards with advanced gas treatment.
Adaptable: Multiple model sizes available to suit varying waste disposal needs.
Packing and Delivery
1. Waterproof packing with the international export standard by 20ft, 40ft, 40hp container. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
2. The whole plant machinery size are large as normal, so we will use Waterproof cloth to pack all of them. The motor, gear box or other easily damaged parts, we will put them into box. We have a professional shipping department, they will try their best to save your container quantity.
FAQ:
Q: Are You Trading Company Or Manufacture?
A: We Are Both Manufacture And Trading Company. We Have Over 30 Years' Professional Experience As a Waste Water Treatment Equipment Manufacturer And Engineering Service Enterprise.
Q : What Are Your Main Products?
A:Keywords :Sludge Dewatering Machine Equipment, Screw Type Sludge Dewatering Press Sludge Screw Press, Dewatering Sludge Machine Screw Press ,Sewage Treatment Equipment ,Sludge Treatment Plant,Screw Press Sludge Dewatering ,Dewatering Sludge,Dewatering Machine For Sludge, Dewatering Sludge Machine Screw Press, Rotary Drum Bar Screens, Equipment DAF, DAF Price ,Dissolved Air Flotation System Price, Sludge Shaftless Screw Conveyor,Chemical Dosing Device ,MBBR Price,MBBR Media,Disc Diffuser, Polymer Preparation Chemical Dosing System, and other customized machines.
Q: How Can I Find The Suitable Model?
A: Please Provide Flow Rate, Solids Content And Sludge Type, or directly contact us by the clicking the “contact” icon. We Can Assist You In Model Selection.
